Fluent fabricates custom steel chutes for new conveyors and retrofit installations. Chutes for belt-to-belt transfer, sorting discharge, and poker picker separation. Engineered to your belt width, material characteristics, and plant layout, and built in the US.
Define the key dimensions, materials, capacity, and wear requirements for reliable material transfer and controlled flow throughout your conveyor system.
24–120" (custom widths available)
45–75° — material-dependent
2–50 ft
10–500+ TPH
1.25–1.5× nominal TPH
Carbon steel (ASTM A36), stainless steel (304/316), aluminum
3/16"–1/2" depending on structural material and application
AR400/AR450/AR500 steel, UHMW polyethylene, rubber (40A–60A durometer), ceramic tile
1/4"–2" depending on material and application
Replaceable bolt-on panels; panel sizing optimized for two-person handling
Integrated seals, hooded designs, collection system ports
Powder coat, zinc-rich epoxy, hot-dip galvanizing
-40°F to 180°F (material-dependent)
USA
Poker picker configuration is driven by material composition, burden depth, and required separation efficiency. Lane spacing (3–8", adjustable) and detection range are set per application; quick-change dividers allow reconfiguration without downtime. Separation efficiency runs 85–95% across rated capacity, depending on technology selection and material consistency.
Separation technology selection depends on the material ferrous content and the required efficiency:
36–96" (custom widths available)
20–200 TPH
3–8" adjustable
4–12"
85–95% across rated capacity
Mechanical fingers, magnetic (1,000–2,000 gauss), hybrid
50–150 FPM
ASTM A36 steel, 3/16" wall rectangular tubing
15–35 linear ft
55–60° minimum
460V three-phase, 15–50 HP
90 PSI minimum, 10–30 CFM
NEMA 4/4X available
Fluent retrofits chutes onto conveyors of any make. We work from your drawings or field measurements. Fabricated chute ships ready to install.
Prepare the following specifications to help us quote you accurately:
Receiving belt width
Discharging belt width
Belt speed (discharge conveyor)
Drop height
Material type
Maximum lump size
Throughput
Transfer direction
Available headroom and footprint
Existing drawings or field dimensions
Partial specifications are fine. We can work with you to determine the rest.
Fluent builds custom conveyors from the ground up. The same engineering team that specs drives, belts, and controls also designs our chutes. Every chute ships from our 85,000 sq ft US facility, fabricated by certified welders and finished with industrial powder coat.
For new Fluent systems, chutes are delivered as part of the build. For retrofits, the same standards apply regardless of the receiving conveyor's make.
Fabricated in the USA by certified welders
Color matched to your equipment
Available as part of a new Fluent system or standalone retrofit
