Replacement Conveyor Pulleys

Pulleys are offered in CEMA duty, mine duty & super duty with multiple bushings (XT, QD, Tape-Lock) as well as multiple lagging options.

Download Brochure
Lead Time
2 - 4 Weeks (Standard Lead Times)

Replacement Conveyor Pulley Overview

Crowned and Lagged Head Pulleys

Crowned and Lagged Head Pulleys

Herringbone Winged Tail Pulleys

Herringbone Winged Tail Pulleys

Standard Winged

jasdfhldlkf

Sprial

Sprial

Engineered Class Pulley Specifications & Options
Pulley Types Offered
  • CEMA Drum Pulleys (Diameter: 4” to 60”)
  • CEMA Winged Pulleys (Diameter: 6” to 60”)
  • Herringbone / Chevron Winged Pulleys (Diameter: 10” to 48")
  • Mine Duty Winged Tail Pulleys (Diameter: 10” to 60”)
  • Spiral Winged Pulleys
  • Mine Duty Drum Pulleys (Diameter: 10” to 60”)
  • Mine Duty Winged Pulleys (Diameter: 10” to 60”)
  • Super Duty Pulleys (Extra Heavy Duty - Diameter: 10” to 60”)
  • Spiral Drum Pulley
  • Dead Shaft Pulleys
  • Disc Return Rollers
  • Beater Bars
  • Custom pulley designs upon request
Bushing Options
  • TL - Taper Lock
  • XT
  • QD
  • KLD - Keyless Locking Device
Lagging Materials
  • SBR
  • Neoprene
  • Static Conductive Neoprene
  • SAR
  • Urethane
  • Husky
  • SOF
  • MSHA
  • Cold Bond rubber lagging available on request
Lagging Type
  • Smooth
  • Chevron
  • Herringbone
  • Diamond
  • Ceramic
  • Vulcanized Ceramic
  • Slide Lag
  • We offer relagging of current non-damaged drums
Lagging Options:
  • Pattern: Chevron - Compound: SBR, SAR, MSHA - Durometer: 45, 60 - Thickness: 3/8, 1/2, 5/8, 3/4, 1
  • Pattern: Herringbone - Compound: SBR, SAR, MSHA - Durometer: 45, 60 - Thickness: 3/8, 1/2, 5/8, 3/4, 1
  • Pattern: Smooth- Compound: SBR, SAR, Urethane, MSHA - Durometer: 45, 60 - Thickness: 3/8, 1/2, 5/8, 3/4, 1
  • Pattern: Holz Slide Lag- Compound: SBR, SOF, Husky - Durometer: 45, 60 - Thickness: 9/16, 3/4
  • Pattern: Ceramic- Compound: SBR, MSHA - Thickness: Based on application
  • Pattern: Urethane- Compound: Urethane - Durometer: 80, 90 - Thickness: Based on application
  • Custom options are available upon request and may or may not be available. These are looked at on a case by case basis.
Hub Design Options
  • Class One - Welded Hub
  • Class Two - Integral Hub
  • Class Three- Profile Disc
  • Class Four-Turbine End Disc
  • Class Five - T-Section
Duty Option
  • CEMA Rated
  • Prime
  • Mine Duty
  • Super Duty
  • Custom
Profiles
  • Flat
  • Spiraled
  • Crowned
  • Trapezoidal Crown
We Offer 100's Of Additional Options For Replacement Conveyor Components

As well as producing bespoke conveyor systems, we also supply custom replacement belts and parts to ensure no client sees their assembly line stay offline for an extended period of time. From replacement motors to sprockets, everything is covered if a client comes across a failing element of their conveyor system.

Sadly, it’s inevitable your clients will face some type of issue with their conveyor system at some point. Even with Fluent Conveyors’ best equipment in place, conveyors are going to suffer from wear and tear due to their demanding nature. However, being able to offer a solution at any time will be appreciated by your clients.

Request a Quote For Your Replacement Conveyor Pulley

Are You Looking For A Easy & Seamless Way To Order New Conveyor Pulley?

Please Contact Us If You Want Us To Help & You Are Comfortable With The Following:

    1. Price Can Range For Each Shaft From $1,000 - $30,000+
    2. Lead Time of 1 – 5 Weeks+ (Depending on pulley requirements)
    3. You have visited our resource center and have all the required dimensions
    4. Have the ability to review & sign approval drawings
    5. 100% pre-payment before manufacturing. These are made to order per your specifications & can't be returned
    Frequently Asked Questions
    • How to locate the drive pulley on a conveyor belt?

      If you have a Fluent Conveyors machine, the drive pulley is typically the pulley at the end of the conveyor that material is moving towards. If your belt moves in both directions this will be at the end that pulls the largest loads or the belt runs in the direction the most.

      If you have a Fluent Conveyors Package Handling conveyor then the drive pulley can be in the middle of the conveyor or at the end. The drive pulley will have a chain and sprocket on one side of it that is attached to a motor. If it is a vanline conveyor it will have a motorized pulley so the drive pulley will be the largest diameter pulley in the drive in the middle of the conveyor.

      If you have a conveyor that is manufactured by someone other than Fluent Conveyors there are several ways to locate the drive pulley. First, the drive pulley must be driven. This means it will be near where the power is routed to the conveyor. Next it will be driven so it will either have a motor/gearbox mounted directly to the pulley or attached to it via chain and sprocket (or timing belt). Other considerations to help narrow this down are as follows; the drive pulley is usually at the end of the conveyor that the material is moving towards, the drive pulley is usually coated in lagging (rubber) to increase friction between it and the belt, the drive pulley is typically the largest pulley in the drive system.

      Please contact Fluent Conveyors if you have any further questions.

    • How many types of conveyor pulleys are there?

      There are thousands of pulley options that all have a specific application for their needs. Fluent offers bulk handling head and tail pulleys for the waste and recycling industry.

      Core pulley offerings include but are not limited to: Drum pulleys, mine duty, spiral drum, chevron pulley, winged tail pulleys and more.

      If you have specific lagging patterns, thicknesses and crowning please contact our sales team.

    • What drives the conveyor belt?

      Conveyor belts are driven by a motor, gearbox, shaft and either a pulley or sprockets. You will also find pneumatic conveyors.

    • How long will it take to deliver a replacement pulley?

      Replacement pulley lead times vary depending on the complexity of the pulley as well.

      The delivery timing will depend on the internal product load of our facility, access to materials for your pulley, bushing types etc.

      Your sales representative will get you an approximation at the time of quote.
